Pivot Shuttle SL Ride SLX XT full suspension mountain bike Blue Denim lightweight design for trail and enduro riding

Pivot Shuttle SL Ride SLX XT Mountain Bike Blue Denim

0 reviews|Write a review

$3,694.24

Brands Pivot Cycles
Product Code: 00SSLV129ASXA--BLDXLDRPINSA1
Availability: In Stock

Pivot Shuttle SL Ride SLX/XT – Blue DenimThe Pivot Shuttle SL Ride SLX/XT is a lightweight, full-suspension electric mountain bike designed to deliver the responsive feel of a traditional trail bike with the added climbing support of an e-bike. Finished in Blue Denim, it combines a lightweight carbon frame, progressive trail geometry, 132 mm of rear travel, and a 150 mm FOX front fork with the smo..

Available Options

Size

Qty:

Description
Reviews (0)

Lightweight Full Suspension Bike for Trail and Enduro Riding

Pivot Shuttle SL Ride SLX/XT – Blue Denim

The Pivot Shuttle SL Ride SLX/XT is a lightweight, full-suspension electric mountain bike designed to deliver the responsive feel of a traditional trail bike with the added climbing support of an e-bike. Finished in Blue Denim, it combines a lightweight carbon frame, progressive trail geometry, 132 mm of rear travel, and a 150 mm FOX front fork with the smooth and compact FAZUA Ride 60 drive system.

The result is an e-MTB that feels natural and agile on the trail while providing extra assistance on steep climbs and longer rides. The motor and battery are positioned low in the frame to help keep the center of gravity low and the bike's handling balanced.

Key Features

Hollow Core Carbon frame – Lightweight carbon construction provides a responsive platform while keeping the bike's overall weight down.
FAZUA Ride 60 motor – Delivers up to 60 Nm of torque with a natural, responsive assist character.
Integrated 430 Wh battery – Provides substantial energy capacity while keeping the battery neatly incorporated into the downtube.
132 mm rear suspension – Pivot's rear suspension platform is designed to balance pedaling efficiency, traction, and control.
150 mm FOX Performance 36 fork – Provides additional capability for technical terrain and aggressive trail riding.
FOX Float X Performance shock – Controls the rear suspension and complements the bike's progressive chassis.
Shimano SLX/XT 12-speed drivetrain – Combines an SLX shifter and cassette with an XT rear derailleur for reliable shifting across a wide gear range.
Shimano SLX four-piston brakes – Strong hydraulic braking performance for steep descents and demanding trails.
29-inch wheels – Help the bike maintain momentum and roll efficiently over rocks, roots, and rough surfaces.
DT Swiss M1900 wheelset – Durable alloy wheels with a 30 mm internal rim width.
E13 Vario dropper post – Allows the saddle height to be adjusted from the handlebar while riding.
Adjustable geometry – A flip-chip system allows riders to modify the bike's geometry and also supports mixed-wheel configurations.
Internal cable routing – Keeps the cockpit and frame clean while protecting cables and housing.

FAZUA Ride 60 Drive System

At the heart of the Shuttle SL is the FAZUA Ride 60 drive system. The compact motor produces up to 60 Nm of maximum torque, with up to 450 W of peak power and 250 W of continuous rated power.

Unlike heavier e-bike systems, the Ride 60 was selected for its compact dimensions and low weight. The motor and battery sit low and close to the center of the bike, helping preserve the lively handling expected from a trail-oriented mountain bike.

The system's assistance settings can also be customized through the FAZUA mobile application, allowing riders to adjust the motor's behavior to their preferences and riding conditions.

Integrated 430 Wh Battery

The Shuttle SL uses an integrated 430 Wh battery housed within the downtube. Its placement keeps the weight centralized and contributes to the bike's clean appearance.

A 210 Wh range extender is available as an optional accessory for riders who need additional riding range.

Carbon Frame and Suspension

Pivot builds the Shuttle SL around a Hollow Core carbon frame, including carbon front and rear triangles. Molded protection is incorporated around the chainstay, seatstay, and downtube areas to help protect the frame during demanding trail use.

The suspension combines a FOX Performance 36 fork with 150 mm of travel and a FOX Float X Performance rear shock. The rear suspension provides approximately 132 mm of travel, giving the bike enough movement to handle technical trail surfaces while remaining efficient during climbs and flatter sections.

Shimano SLX/XT 12-Speed Drivetrain

The Ride SLX/XT build uses a mixed Shimano drivetrain that pairs dependable SLX controls and cassette components with an XT rear derailleur.

The 10–51T cassette provides a wide range of gearing. The 51-tooth largest sprocket gives the rider a low climbing gear for steep terrain, while the higher gears remain useful on faster sections of trail.

Drivetrain Components

Shimano XT M8100 SGS 12-speed rear derailleur
Shimano SLX M7100 12-speed shifter
Shimano SLX M7100 10–51T cassette
Shimano CN-M7100 12-speed chain
PRAXIS ETOR E-MTB 32T crankset

Shimano SLX Four-Piston Brakes

The bike is equipped with Shimano SLX M7120 four-piston hydraulic disc brakes. Large 203 mm front and 180 mm rear Galfer rotors provide strong braking performance for technical descents, steep trails, and repeated braking.

The four-piston SLX system is well matched to the Shuttle SL's all-mountain and trail-oriented design.

DT Swiss M1900 Wheels

The Shuttle SL Ride SLX/XT uses DT Swiss M1900 alloy wheels with a 30 mm internal rim width. The wheelset uses DT Swiss 370 hubs with a 15 x 110 mm Boost front axle and 12 x 157 mm SuperBoost+ rear axle.

The 29-inch wheel format provides efficient rollover and helps the bike maintain momentum across uneven terrain.

Trail-Ready Tires

The bike is equipped with Maxxis Dissector 29 x 2.4-inch WT tires in the Ride SLX/XT specification. The tires use tubeless-ready construction and a 3C EXO MaxxTerra configuration, providing a balance of traction, cornering performance, and puncture protection for trail riding.

Adjustable Geometry

A two-position flip chip in the upper linkage allows the rider to alter the Shuttle SL's geometry. The system can also accommodate a mixed-wheel setup, with a 29-inch front wheel and 27.5-inch rear wheel in the appropriate configuration.

This gives riders additional flexibility when choosing between a more stable 29er setup and a more agile mixed-wheel configuration.

Technical Specifications

Specification	Details
Brand	Pivot Cycles
Model	Shuttle SL Ride SLX/XT
Color	Blue Denim
Bike Type	Full-suspension electric mountain bike
Frame	Hollow Core Carbon
Wheel Size	29 in.
Rear Travel	132 mm
Fork	FOX Performance 36 E-MTB
Fork Travel	150 mm
Fork Offset	44 mm
Fork Damper	GRIP
Rear Shock	FOX Performance Float X
Rear Shock Size	185 x 55 mm, trunnion mount
Motor	FAZUA Ride 60
Maximum Torque	60 Nm
Continuous Motor Power	250 W
Peak Motor Power	450 W
Battery	Integrated FAZUA 430 Wh
Optional Range Extender	210 Wh
Rear Derailleur	Shimano XT M8100 SGS, 12-speed
Shifter	Shimano SLX M7100 I-Spec EV, 12-speed
Crankset	PRAXIS ETOR E-MTB, 32T
Cassette	Shimano SLX M7100, 10–51T
Chain	Shimano CN-M7100, 12-speed
Brakes	Shimano SLX M7120, 4-piston hydraulic
Front Rotor	Galfer 203 mm
Rear Rotor	Galfer 180 mm
Wheels	DT Swiss M1900 Alloy
Rim Width	30 mm internal
Front Hub	DT Swiss 370, 15 x 110 mm Boost
Rear Hub	DT Swiss 370, 12 x 157 mm SuperBoost+
Tires	Maxxis Dissector 29 x 2.4 in. WT
Handlebar	Phoenix Race Low Rise Aluminum, 780 mm
Stem	Phoenix Team Enduro/Trail, 45 mm
Grips	Phoenix Factory Lock-On
Dropper Post	E13 Vario
Dropper Travel	150–180 mm for S/M; 180–210 mm for L/XL
Saddle	Phoenix WTB Volt Race, medium width
Headset	Pivot Precision Sealed Cartridge
Cable Routing	Internal
Intended Use	Trail / All-Mountain

Specifications are based on the Ride SLX/XT Blue Denim configuration and current/archived Pivot build information. Pivot notes that bicycle components may change without prior notice.

Available Sizes

The Shuttle SL Ride SLX/XT is available in:

Small (S)
Medium (M)
Large (L)
Extra Large (XL)

The frame also offers low/high geometry positions through its flip-chip system.

Ideal for

The Pivot Shuttle SL Ride SLX/XT is a strong choice for riders who want:

Technical trail riding
All-mountain adventures
Long-distance mountain rides
Steep climbing
Fast and technical descents
Rough singletrack
Natural-feeling e-bike assistance
A lighter, more agile alternative to heavier full-power e-MTBs

Why Choose the Pivot Shuttle SL Ride SLX/XT?

The Shuttle SL Ride SLX/XT is designed around balance rather than simply maximum motor output. Its lightweight carbon chassis, compact FAZUA motor, centralized battery, progressive suspension, and 29-inch wheels create an e-bike that is intended to retain the responsive feel of a conventional trail bike while adding useful electrical assistance.

With 150 mm of FOX front travel, 132 mm of rear travel, Shimano SLX/XT 12-speed gearing, four-piston SLX brakes, and DT Swiss M1900 wheels, the Blue Denim Shuttle SL is equipped for riders who want a versatile machine capable of climbing efficiently and remaining confident when the trail becomes steep, rough, and technical.
