Gazelle Ultimate T10+ Mid-Step Bicycle Dust Light Gloss
- $1,333.77
- Brands Gazelle
- Product Code: G2415
- Availability: In Stock
Gazelle Ultimate T10+ Mid-Step – Dust Light GlossThe Gazelle Ultimate T10+ Mid-Step is a sporty, comfortable Class 3 electric bicycle designed for fast commuting, longer recreational rides, and everyday transportation. Its Dust Light Gloss finish gives the bike a clean, understated appearance, while the integrated Bosch motor and battery create a streamlined look.At the heart of the Ultimate T10+ ..
Available Options
Features and Benefits of Gazelle Ultimate T10+ Mid-Step in Dust Light Gloss
Gazelle Ultimate T10+ Mid-Step – Dust Light Gloss
The Gazelle Ultimate T10+ Mid-Step is a sporty, comfortable Class 3 electric bicycle designed for fast commuting, longer recreational rides, and everyday transportation. Its Dust Light Gloss finish gives the bike a clean, understated appearance, while the integrated Bosch motor and battery create a streamlined look.
At the heart of the Ultimate T10+ is a Bosch Performance Line Speed mid-drive motor producing up to 85 Nm of torque and assistance up to 28 mph. The integrated 500 Wh Bosch battery supplies power for extended rides, while the 10-speed Shimano Deore drivetrain provides a broad range of gears for varied terrain.
The mid-step aluminum frame provides a useful balance between sporty handling and easier mounting compared with a traditional high-step frame. Gazelle also equips the bike with a suspension fork, wide puncture-resistant tires, ergonomic grips, hydraulic disc brakes, integrated lighting, and a rear rack for practical everyday use.
Key Features
Bosch Performance Line Speed motor delivers up to 85 Nm of torque.
Class 3 pedal assistance supports speeds up to 28 mph.
500 Wh integrated Bosch battery provides substantial riding range while keeping the frame cleanly styled.
10-speed Shimano Deore drivetrain offers a wide range of gearing for commuting and hills.
Shimano BR-MT420 hydraulic disc brakes provide strong, controlled braking.
SR Suntour MOBIE 45 suspension fork provides 80 mm of travel to help smooth uneven pavement and paths.
Mid-step aluminum frame combines stable handling with easier step-over access.
Dust Light Gloss finish gives the bike a refined, contemporary appearance.
Wide, puncture-resistant tires improve comfort and everyday durability.
Ergon GP1-L ergonomic grips help distribute pressure across the hands.
Adjustable stem allows the riding position to be tailored to the rider.
Selle Royal Essenza saddle provides a comfortable platform for longer rides.
AXA Blue Line 50 front light and Herrmans H-Cargo rear light provide integrated visibility.
Aluminum rear rack adds practical carrying capability.
AXA ring lock provides built-in basic bicycle security and can accept a compatible plug-in cable.
Walk assist helps maneuver the e-bike when walking beside it.
Bosch Performance Line Speed Motor
The Ultimate T10+ uses Bosch's Performance Line Speed mid-drive system. With up to 85 Nm of torque, the motor is designed to provide strong assistance when accelerating, climbing hills, or maintaining speed.
The motor is positioned centrally in the frame, helping maintain balanced handling while keeping the bike's overall design clean. The system offers four assistance modes: Eco, Tour, Sport, and Turbo, allowing riders to choose between efficiency and stronger motor support.
500 Wh Integrated Battery
A 500 Wh Bosch PowerTube-style integrated battery is housed within the frame. Integrating the battery into the frame improves the bike's appearance while keeping the center of mass low.
Gazelle lists estimated ranges of approximately 94 miles in Eco, 56 miles in Tour, 44 miles in Sport, and 38 miles in Turbo under its specified test conditions. Actual range will vary according to rider weight, terrain, temperature, tire pressure, wind, riding style, and assistance level.
The battery is rated at 36 V and 13.5 Ah, and Gazelle lists approximately 4.5 hours charging time with the included 4A charger.
10-Speed Shimano Deore Drivetrain
The Shimano Deore 10-speed drivetrain provides a broad selection of gears for everyday riding. Riders can select lower gearing for climbs and higher gearing for maintaining speed on flatter roads.
The 10-speed setup complements the Bosch Performance Line Speed motor, giving the rider mechanical gearing options in addition to the electronic assistance modes.
Hydraulic Disc Braking
Stopping power comes from Shimano BR-MT420 hydraulic disc brakes. Hydraulic actuation provides controlled braking through a sealed system, while the disc-brake configuration is well suited to a performance-oriented e-bike that can reach Class 3 speeds.
The system is particularly useful when riding in changing conditions or carrying additional weight on the rear rack.
Suspension and Riding Comfort
The Ultimate T10+ combines sporty geometry with components intended to make longer rides more comfortable. Its SR Suntour MOBIE 45 fork provides 80 mm of suspension travel and includes a lockout function.
Wide tires and ergonomic Ergon GP1-L grips further reduce the harshness of rough pavement. The slightly curved aluminum handlebar and adjustable stem allow the rider to fine-tune the cockpit position.
Mid-Step Frame Design
The mid-step aluminum frame provides easier access than a conventional high-step configuration while retaining the stable, sporty characteristics associated with the Ultimate platform.
Gazelle lists the Dust Light Gloss mid-step configuration in 46 cm, 53 cm, and 57 cm frame sizes. The published geometry information places the corresponding mid-step standover heights at approximately 747 mm, 770 mm, and 796 mm, respectively.
Integrated Lighting and Utility Equipment
The Ultimate T10+ is equipped for everyday transportation rather than being limited to recreational riding. Its battery-powered AXA Blue Line 50 front light and Herrmans H-Cargo rear light provide integrated illumination and visibility.
The aluminum rear rack adds carrying capacity for commuting essentials, while the AXA ring lock provides convenient built-in security.
Product Specifications
| Specification | Details |
|---|---|
| Brand | Gazelle |
| Model | Ultimate T10+ HMB |
| Frame Style | Mid-Step |
| Color | Dust Light Gloss |
| Bike Category | Electric Trekking / Commuter E-Bike |
| Frame Material | Aluminum |
| Available Frame Sizes | 46 cm, 53 cm, 57 cm |
| Motor | Bosch Performance Line Speed |
| Motor Position | Mid-drive |
| Maximum Torque | 85 Nm |
| Maximum Assisted Speed | 28 mph |
| E-Bike Class | Class 3 |
| Battery | Bosch 500 Wh Integrated |
| Battery Voltage | 36 V |
| Battery Capacity | 13.5 Ah |
| Charger | Bosch 4A |
| Charging Time | Approx. 4.5 hours |
| Display | Bosch Purion LCD |
| Assist Modes | Eco, Tour, Sport, Turbo |
| Walk Assist | Yes |
| Drivetrain | Shimano Deore |
| Number of Gears | 10 |
| Brakes | Shimano BR-MT420 Hydraulic Disc |
| Front Fork | SR Suntour MOBIE 45 |
| Fork Travel | 80 mm |
| Fork Lockout | Yes |
| Handlebar | Aluminum, Slightly Curved |
| Grips | Ergon GP1-L Ergonomic |
| Stem | Adjustable |
| Saddle | Selle Royal Essenza |
| Front Light | AXA Blue Line 50 |
| Rear Light | Herrmans H-Cargo |
| Rear Rack | Gazelle Aluminum |
| Lock | AXA Ring Lock |
| Weight | Approx. 51.1 lb / 23.2 kg, excluding battery |
| Eco Estimated Range | Up to 94 miles |
| Tour Estimated Range | Up to 56 miles |
| Sport Estimated Range | Up to 44 miles |
| Turbo Estimated Range | Up to 38 miles |
Specifications and range figures are based on Gazelle's published Ultimate T10+ information; actual performance and range can vary with riding conditions and configuration.
Ideal for Commuting and Longer Rides
The Gazelle Ultimate T10+ Mid-Step is well suited for:
Daily commuting
Fast urban transportation
Recreational cycling
Long-distance paved-road rides
Hilly commutes
Bike-path riding
Fitness-oriented cycling
Everyday errands
Its combination of high-speed Bosch assistance, 10-speed gearing, suspension, hydraulic braking, integrated lighting, and rear cargo capacity makes it a versatile choice for riders who want an e-bike that can handle both transportation and recreational use.
A Sporty E-Bike With Everyday Comfort
The Gazelle Ultimate T10+ Mid-Step – Dust Light Gloss combines the responsive character of a performance-oriented e-bike with the practical equipment expected from a daily commuter. The 85 Nm Bosch Performance Line Speed motor, 500 Wh integrated battery, 10-speed Shimano Deore drivetrain, hydraulic disc brakes, suspension fork, ergonomic controls, lighting, and rear rack give it the equipment needed for demanding everyday riding.
For riders looking for a fast, stable, and comfortable electric bicycle with a more accessible mid-step frame, the Ultimate T10+ offers a well-balanced combination of performance, comfort, and practical utility.
